Industrial Power Supply 24Vdc 2,3 Phase 230-400-500Vac 7.5A
SKU: FLEX17024B
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Switching power supplies for DIN rails.
Very tiny size, with a 150% power increase and a wide input voltage range of 110-230-400-500 Vac.
The output protection mode is selectable.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Input: 230 – 400 – 500 Vac.
Output: 24 Vdc 60°C.
Strong overload without switch-off, up to 50%.
Flexible Power continuity: from 120 to 180 W.
Three mode of output protections:
Manual Reset
Hiccup Mode
Continuous Out Mode
DIN Rail Mountable.
Extremely small size.
Protection Class: IP 20.
Connection Terminal Blocks Screw Type: 2,5 mm2 (24 – 14 AWG).
Dimension (w-h-d): 55x110x105 mm.
Input Data:
Input Voltage range:
230: 187-264 Vac
400-500: 330-550 Vac 462-770 Vdc
Frequency: 47 – 63 Hz.
Input Current (230 – 400 – 500 Vac): 1.45 – 0.83 – 0.68 A.
Internal Fuse: T 4 A.
External Fuse: 10 A (MCB curve B).
Output Data:
Output Voltage: 24 Vdc.
Adjustment range: 22 – 27 Vdc.
Max current Short Circuit: 16 A.
Over temperature Protection: Shut-down output and automatic restart.
Overload protection.
Climatic Data:
Ambient Temperature:
Operation: -25 up to +70 °C.
Storage: -40 up to +85 °C.
Humidity at 25 °C, no condensation: 95 % to 25 °C.
