PG16 22.5MM PVC Compression Gland Black
SKU: GLA-0014-H09
Sold by Select Automation
Final price R 16.48
R 14.33 excl. VAT
Availability: In Stock (2 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The PG16 22.5mm PVC Compression Gland Black is a cable-entry and strain-relief fitting used to route cables safely thru electrical panels, junction boxes, and enclosures.
Its compression design secures the cable while also protecting the entry point from dust, moisture, and mechanical stress.
The PG16 gland has a thread diameter of 22.5mm and is appropriate for cables ranging in diameter from 10 to 14mm.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Material: High-quality PVC.
Thread Diameter: PG16 with an outer diameter of 22.5 mm.
Compress Area: Suitable for cables with diameters ranging from 10 mm to 14 mm.
Dimensions: 29-43 mm (length) x 9 mm (width) x 16 mm (thickness).
Weight: Approximately 0.024 kg (24 grams).
Protection: Rated IP68 to EN 60520 and IP69K to DIN 40 050-T9, offering high levels of protection against dust and water.
Flame Protection: Glow wire test 750°C according to EN60695-2-11.
Temperature Range: Suitable for use in temperatures ranging from -40°C to +100°C.
Colour: Black.
Applications: Ideal for indoor and outdoor installations, providing secure fastening and protection for cables in various environments.
