RCC Logic controller without display. 14 digital DC inputs,10 digital outputs,
SKU: HE-RCC1410-75
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The RCC1410 is an RCC controller featuring ten (10) DC outputs at.5A per point and fourteen (14) digital inputs that are compatible with 12V/24VDC.
With 10 digital outputs and 14 digital DC inputs, users can choose from a wide selection of outstanding I/O solutions for Discrete Manufacturing and Process applications.
offers enhanced connection by default supporting both 10/100 Ethernet and CAN.
With CAN included, the RCC can use Horner's CsCAN to support hundreds of remote I/O points.
Buy currently uses Select Automation shop pricing and checkout.
Controller:
Protocols: CsCAN, Ethernet
Ethernet Connector: RJ45, Auto MDIX
Serial Port: 2 (1xRS232, 1×2-wire RS485)
Program Memory Size: 128 KB
Floating Point Support: Yes
Autotune PID Capable: Yes
Removable Memory: microSD
I/O:
Built-in I/O Points: 24
Digital DC Inputs per Module: 14
DC Digital Input Voltage Range: 12 VDC / 24 VDC
Digital DC Outputs per Module: 10
Digital DC Output – Max Output Supply Voltage: 30 VDC
Digital DC Output – Max Inrush Current: 500mA per channel
SmartStix, SmartRail, SmartBlock I/O Support: CsCAN & Ethernet
Digital Inputs / Outputs, Max: 2048 / 2048
Analog Inputs / Outputs, Max: 512 / 512
General Purpose Registers (words): 50000
General Purpose Internal Coils (bits): 32768 (16384 retentive)
Ethernet / Internet:
Ethernet Support: Standard
Remote Access: HTTP or EnvisionRV
Remote File Access: FTP or EnvisionFX
WebOCS Compatibility (Licensed Option): WebMI
