PACSystems™ RX3i Analog Output module, current, 2 channel
SKU: IC694ALG391
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Product Description:
RX3i IO is designed for mission critical discrete and process applications.
The rack-based IO offers advanced diagnostics and outstanding flexibility, with a wide range of standard and advanced IO.
High-speed and patented technology for faster throughput.
Each Channel converts 12 bits a configurable 0 to 20mA or 4-20mA.
Can be installed in any I/O slot in an RX3i system.
Jumper configurable to default to 0/4mA or Hold-Last-State if the CPU goes into Stop or Reset.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Part Number: IC694ALG391
Analog Output Count Type: 2 Channel; 4-20 mA, 0-20 mA (or with slightly less accuracy, 1-5 V and 0-5 V)
Resolution Speed: 12 Bit; 5mS
Current Consumption: 30 mA @ 5 VDC; 215 mA 24 VDC Isolated
Agency: UL, UL HAZLOC, CE EMC LV Directives
Approvals: Zone 2 CE, ATEX C1D2 ABS, BV, DNV, GL, KRS, LR
Mounting Format: RX3i Rack
