PACSystems™ RX3i DC Voltage Input module, 48V, 16 point
SKU: IC694MDL648
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Product Description:
RX3i IO is designed for mission critical discrete and process applications.
The rack-based IO offers advanced diagnostics and outstanding flexibility, with a wide range of standard and advanced IO.
High-speed and patented technology for faster throughput.
Hot swap capability.
A variety of voltage ranges, types, current capacity, isolation and response time to meet your application needs.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Part Number: IC694MDL648.
Input Count, Type Speed16 Point; Pos/Neg Logic; Isolated; 1mS on/1mS Off.
Supply Voltage and on/Off Voltage: 48VDC; Range 40~60V; On 34.
Backplane Current Consumption: 80mA @ 5VDC.
Approvals Standards Ordinary Locations: UL 508, equivalent to CSA C22.2 No 142M1987 standard.
Approvals & Standards Hazardous Locations: Class I, Div. 2, Groups A, B, C, D.
Mounting Format: On Panel/DIN Rail.
