74HC164D Shift Register, Serial To Parallel 14 PIN
SKU: INC-0057-C03
Sold by Select Automation
Final price R 2.12
R 1.84 excl. VAT
Availability: In Stock (25 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 74HC164D is an 8-bit shift register integrated circuit with serial-in and parallel-out capabilities.
It accepts serial data and converts it to parallel data, making it an essential component in digital systems for increasing input/output capabilities and enabling data transfer.
This shift register is built in a 14-pin DIP design and offers dependable performance for a wide range of applications.
The 74HC164D is suited for applications that demand efficient data serialization, I/O expansion, and dependable data transport in digital systems.
Its ability to operate at high speeds while using little power and with great noise immunity makes it a versatile and valuable component.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Register Type: 8-bit Serial-in/Parallel-out.
Package Type: DIP-14 (Dual In-line Package with 14 Pins).
Supply Voltage Range: 2.0V to 6.0V.
Quiescent Current: 80 µA.
Operating Temperature Range: -40°C to 85°C.
Maximum Clock Frequency: 56 MHz.
Output Current High: -7.8 mA (at 5V).
Output Current Low: 7.8 mA (at 5V).
Propagation Delay Time: 15 ns at 5V.
Setup Time (Data): 3 ns at 5V.
Hold Time (Data): 4 ns at 5V.
Asynchronous Clear: Yes (Active Low).
Input Protection: Clamping Diodes.
