ADS1218Y/250 SERIAL ADC PSEUDO DIFFERENTIAL SINGLE ENDED INPUT 48 PIN TQFP 24-bit
SKU: INC-0062-C03
Sold by Select Automation
Final price R 547.37
R 475.97 excl. VAT
Availability: In Stock (1 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Texas Instruments created the ADS1218 as a high accuracy, 24-bit ADC.
This IC's pseudo-differential and single-ended input designs enable it to convert analogue signals into high-resolution digital data.
It comes in a 48-pin TQFP format and is ideal for a variety of precision measurement applications.
The ADS1218Y/250 offers great precision and versatility, making it ideal for a variety of applications requiring accurate data translation and low power consumption.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Resolution: 24 Bits (21 Effective Bits).
Number of Input Channels: 8 Single-Ended or 4 Differential.
Supply Voltage Range: 2.7V to 3.6V.
Common-Mode Input Voltage Range: 0V to VCC.
Maximum Output Data Rate: 780 SPS.
Integral Non-Linearity (INL): ±0.0015%.
Offset Error: ±5 µV.
Gain Error: ±0.4%.
Analog Input Range: 0V to VCC.
Noise-Free Resolution: 20 Bits.
Input Bias Current: 1 nA.
Power Consumption: 2.6 mW.
Temperature Range: -40°C to 85°C.
Programmable Gain: 1 to 128.
Common-Mode Rejection Ratio (CMRR): 100 dB.
Signal-To-Noise Ratio (SNR): 104 dB.
Package Type: 48-pin TQFP.
