MC74HC374ADWG Octal D Type Flip Flop IC, LSTTL, 2, 6 V, 20-Pin SOIC
SKU: INC-0065-C03
Sold by Select Automation
Final price R 8.33
R 7.24 excl. VAT
Availability: In Stock (9 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The MC74HC374ADWG is a high-speed CMOS octal D-type flip-flop with three output states.
It includes eight edge-triggered D-type flip-flops with individual data inputs, clock inputs, and tri-state outputs.
This IC is contained in a 20-pin SOIC (Small Outline Integrated Circuit) package and has a voltage range of 2V to 6V2.
The MC74HC374ADWG includes eight positive-edge-triggered D-type flip-flops with three-state outputs.
On the rising edge of the clock signal, the data on the D inputs is sent to the matching Q outputs.
The output enable (OE) input regulates the output's status, determining whether it is active (low impedance) or disabled (high impedance).
This integrated circuit is appropriate for applications that require digital circuits to store data, drive buses, and buffer.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Type: Octal D-Type Flip Flop.
Package Type: 20-pin SOIC (Small Outline Integrated Circuit).
Number of Flip-Flops: 8.
Supply Voltage Range: 2V to 6V.
Maximum Quiescent Current: 4 µA.
Operating Temperature Range: -55°C to 125°C.
Maximum Clock Frequency: 35 MHz.
Maximum Propagation Delay: 125 ns.
Output Current High: -7.8 mA.
Output Current Low: 7.8 mA.
Input Voltage Range: 0V to VCC.
Input Protection: Clamping Diodes.
3-State Outputs: Yes.
