MC1458cpi magnitude comparator 4-bit non-inverting automotive 16-pin pdip rail
SKU: INC-0074-C03
Sold by Select Automation
Final price R 16.51
R 14.36 excl. VAT
Availability: In Stock (20 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The MC1458cpi is a 4-bit magnitude comparator that compares two 4-bit binary words to determine whether they are greater than, less than, or equal to each other.
It is built with complementary MOS (CMOS) technology, resulting in low power consumption and great noise tolerance.
The MC1458cpi is intended to compare two 4-bit words and find magnitude connections.
It returns three output states indicating whether the first word (A) is less than, equal to, or greater than the second word (B).
The IC can be cascaded to compare bigger words, making it ideal for use in digital systems, instrumentation, test equipment, and control systems.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Comparator Type: 4-Bit Magnitude Comparator.
Package Type: 16-pin PDIP.
Number of Comparing Inputs: 8.
Number of Outputs: 3 (A < B, A = B, A > B).
Supply Voltage Range: 3 V to 18 V.
Input Voltage Range: -0.5 V to VDD + 0.5 V.
Current per Input/Output Pin: ±10 mA.
Power Dissipation: 500 mW.
Operating Temperature Range: -55°C to 125°C.
Storage Temperature Range: -65°C to 150°C.
Lead Temperature: 260°C (for 8 seconds).
