LM324L PRECISION OP AMP 14 PIN
SKU: INC-0120-C05
Sold by Select Automation
Final price R 7.27
R 6.32 excl. VAT
Availability: In Stock (20 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The LM324L is a low-power, quad operational amplifier IC designed for general-purpose analog signal processing. It contains four independent op-amps in a single DIP-14 package, making it ideal for compact designs requiring multiple amplification stages. With a wide supply voltage range and low input bias current, it’s commonly used in audio preamps, sensor interfaces, and active filters. The LM324L is a variant optimized for lower power consumption compared to standard LM324 models.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Type: Quad Operational Amplifier
Package: DIP-14
Number of Channels: 4
Supply Voltage Range: 3V to 40V (single supply)
Input Offset Voltage (Vos): ~5mV
Input Bias Current (Ib): ~250nA
Common Mode Rejection Ratio (CMRR): 75dB
Quiescent Current: Low-power variant (<1mA per amplifier)
Operating Temperature Range: –20°C to +85°C
Output Drive Capability: Moderate (not rail-to-rail)
