ATSAMD20E16A-MU, 32bit Microcontroller, 48MHz, 64 kB Flash, 32-Pin QFN
SKU: INC-0165-C07
Sold by Select Automation
Final price R 54.43
R 47.33 excl. VAT
Availability: In Stock (20 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The ATSAMD20E16A-MU is a 32-bit microcontroller from Microchip Technology that runs on the ARM Cortex-M0+ core.
This microcontroller is noted for its high efficiency and performance, making it suited for a wide range of applications.
Architecture: ARM Cortex-M0+.
Operating frequency: up to 48 MHz.
Flash Memory: 64 kB of in-system self-programmable Flash.
SRAM: 8 kB.
Data Bus Width: 32 bits.
Package type: 32-pin QFN (Quad Flat No Leads).
Buy currently uses Select Automation shop pricing and checkout.
Electrical Characteristics:
Supply Voltage Range: 1.62V to 3.63V.
Maximum Clock Frequency: 48MHz.
Input/Output Pins: 26 I/O.
ADC Resolution: 12-bit with 10 channels.
Temperature Range: -40°C to +85°C.
Performance:
Timers/Counters: Six 16-bit timer/counters.
USART/SPI/I2C Interfaces: Four serial communication modules (SERCOMs) configurable as UART/USART, SPI, or I²C.
Digital-to-Analog Converter (DAC): 10-bit.
PWM Channels: 10.
Real-Time Clock (RTC): 32-bit RTC with clock/calendar function.
