SN74LS76N 4bit-Bit Latch, Transparent, 16-Pin PDIP
SKU: INC-0178-C08
Sold by Select Automation
Final price R 56.51
R 49.14 excl. VAT
Availability: In Stock (22 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Texas Instruments designed the SN74LS76N, a 4-bit bistable latch integrated circuit.
Functionality: This integrated circuit has four D-type flip-flop latch circuits designed to store four bits of data. When enabled, the outputs of each latch are transparent, which means that they follow the inputs if the enable signal is active.
It is packaged in a 16-pin PDIP (Plastic Dual In-line Package), which allows it to be used with standard breadboard layouts for prototyping.
Voltage and Current Specifications: Typically supports a VCC of 5V with maximum output current specs like conventional TTL logic family devices.
Applications: Widely used in computer systems, memory storage, asynchronous systems, and digital logic circuit design to temporarily store and transfer data.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Function: Dual JK Flip-Flop with Set and Clear
Number of Latches: 4 (4-bit storage)
Package Type: 16-Pin PDIP
Operating Voltage: 5V.
Current Specifications: Standard TTL (Transistor-Transistor Logic), with typical current draw of 4mA at 5V.
Propagation Delay: Approximately 15 ns for typical operation.
Input and Output Voltage Levels: VOL (max) 0.35V, VOH (min) 4.5V.
Pin Configuration:
Pins 1-8: Inputs (J, K, Clock, etc.).
Pins 9-16: Outputs (Q, Q', etc.).
Temperature Range: Operation between 0°C to 70°C.
Special Features: Low power consumption, Schottky clamping diodes.
