CD4076BE Flip-Flops 4 Bit D-Type
SKU: INC-0233-C09
Sold by Select Automation
Final price R 39.63
R 34.46 excl. VAT
Availability: In Stock (10 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
An integrated circuit (IC), sometimes known as a microchip or just a chip, is a miniature electronic circuit composed of many transistors, resistors, capacitors, and other components implanted on a small piece of semiconductor material, usually silicon.
These tiny circuits are at the heart of practically all modern electronic gadgets, allowing for extensive functionality while taking up very little space.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Number of Circuits: 2 Circuit.
Output Type: 3-State.
Package/Case: PDIP-16.
Input Type: CMOS.
Polarity: Non-Inverting.
Propagation Delay Time: 600 ns.
High Level Output Current: - 1.5 mA.
Low Level Output Current: 1.5 mA.
Supply Voltage - Min: 3 V.
Supply Voltage - Max: 18 V.
Mounting Style: Through Hole.
Minimum Operating Temperature: - 55 C.
Maximum Operating Temperature: + 125 C.
Function: 4-Bit D-Type.
Height: 4.57 mm.
Length: 19.3 mm.
Number of Channels: 4 Channel.
Number of Input Lines: 4.
Number of Output Lines: 3.
Operating Supply Voltage: 10 V.
Product Type: Flip Flops.
Quiescent Current: 100 uA.
Reset Type: Master Reset.
