TouchMATRIX® Combination Indicator
SKU: IX350
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Description:
The Motrona IX350 touchMATRIX® SSI Indicator is designed to display and process absolute signals from SSI (Synchronous Serial Interface) absolute encoders or sensors.
It features a resistive touchscreen and a multi-colour graphic display, making it user-friendly and versatile for various industrial applications.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
SSI input with format DATA+, DATA-, CLOCK+, CLOCK-.
SSI clock frequencies up to 1 MHz.
Master or Slave operation.
For single turn and multi turn encoders with 10 … 32 Bit.
3 control inputs for HTL / PNP signals.
Power supply 18 ... 30 VDC.
24 V auxiliary output for encoder supply.
3.78 x 1.89-inch norm panel housing and IP65 protection.
Bright and high-contrast display with event-dependent colour variations.
Emulation of a 7-segment display inclusively icons and units.
Intuitive and easy parameterization by plain text and touchscreen.
Operating modes such as scaling and bit blanking.
Linearization with 24 control points.
Options:
Option AC: Power supply 115 ... 230 V AC.
Option AO: 16-bit analog output, 4 control outputs, serial RS232 interface.
Option AR: 16-bit analog output, 4 control outputs, serial RS485 interface.
Option CO: 4 control outputs, serial RS232 interface.
Option CR: 4 control outputs, serial RS485 interface.
Option RL: 2 relay outputs.
