CURRENT MONITOR 0-1A 230VAC
SKU: LA51230A
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Current Monitor:
Installing the Electro 11 pin plug-in series of control and timing devices is simple and straightforward since they are designed to fit into a conventional 11 pin base.
This current monitor is an accurate relay for monitoring current under and over.
The device is perfect for several current monitoring applications because it may be ordered in a variety of AC and DC current ranges.
Separate potentiometers can be used to modify the hysteresis and set point.
Additionally, the machine has a latch feature to stop unnoticed malfunctions.
All units come with a terminating resistor to avoid open circuit in applications that require a CT.
Buy currently uses Select Automation shop pricing and checkout.
Features:
Output 10: An integrated SPDT relay latch facility.
Evaluates individual current input.
Keeping an eye on the current control relay.
Adjustable current limitations on potentiometer.
LEDs for the power supply ON and relay ON.
Adjustable hysteresis limits via potentiometer.
Selecting the rear DIP switch for a 10-second startup delay.
UNDER/OVER current selection via the rear DIP switch.
Specifications:
DESCRIPTION: Current monitor
CONTACT: 10A SPDT
FUNCTION: Over / under current
HYSTERESIS: 5-50%
RATED VOLTAGE: 250V
MECHANICAL LIFE: 10x106 cycles
PROTECTION INDEX IP: IP 20
OPERATING TEMPERATURE: -10 to + 50°C
STORAGE TEMPERATURE: -50 to + 85°C
DIMENSIONS (MM): (H) 92 x (W) 36 x (D) 64
