servomotor MO7221-9016-1114
SKU: MO7221-9016-1114
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The MO7221-9016-1114 servomotor module with integrated absolute value interface offers high servo performance in a very compact design.
Buy currently uses Select Automation shop pricing and checkout.
Product category: I/O modules
Category/version: compact drive technology
Type: servomotor
Feedback: OCT
Channels: 1
Connection method: B17
Drive profile: MDP profile
Safety functions: STO/SS1
Output current: 7 A per channel
Peak current: 16 A/s per channel
Brake per channel: 0.5 A, 24 V DC
Supply voltage from backplane: 24 V DC
DC link voltage: 24 V DC
Baseplate interface: data connector
Diagnostics: yes, status and live data via app
Distributed clocks: yes
Hot swap: yes
TwinCAT version: TwinCAT 3
Weight: approx. 400 g
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 30 mm × 110 mm × 72 mm
Number of rows: 1
Number of slots: 1
Material: zinc and aluminium die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
