75G60HD NPN MOSFET Transistor SMD 600V 75A
SKU: MOS-0072-G13
Sold by Select Automation
Final price R 40.32
R 35.06 excl. VAT
Availability: In Stock (5 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 75G60HD IGBT transistor is a three-terminal power semiconductor device.
Originally utilized as an electrical switch, it evolved to combine high efficiency and quick switching.
Electronic signals can be switched or amplified by utilizing the conductivity's capacity to change with applied voltage.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Type of transistor: IPM.
Type: NPN.
Mounting: Surface mount.
Collector-Emitter voltage: 600V.
Gate-Emitter voltage: ±20V.
DC Collector Current TC=25°C: 100A.
DC Collector Current TC=100°C: 75A.
Pulsed Collector Current: 225A.
IGBT Max. Power Dissipation TC=25°C: 500W.
FWD Max. Power Dissipation TC=25°C: 190W.
Operating Junction Temperature: -40 to +175°C.
Storage Temperature: -55 to +175°C.
