Nema 17 PHB42S40-402 Hybrid Stepper Motor 2 Phase 40mm
SKU: MOT-0012-Q01
Sold by Select Automation
Final price R 328.06
R 285.27 excl. VAT
Availability: In Stock (21 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The PHB42S40-402 is a compact and dependable Nema 17 hybrid stepper motor intended for precise motion control in 3D printers, CNC machines, and robots.
With a body depth of 40mm, it strikes a balance between torque and size, making it perfect for space-constrained installations.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Step Angle: 1.8° per step (200 steps/revolution).
Step Angle Accuracy: ±5% (full step, no load).
Rated Current: 1.7A per phase.
Phase Resistance: 1.5Ω ±10% (at 20°C).
Phase Inductance: 4.5mH ±20% (1kHz, 1V RMS).
Holding Torque: ≥0.4 N·m (≈4 kg·cm).
Temperature Rise: ≤80°C (at rated current, 2-phase on).
Shaft Diameter: 5mm.
Shaft Length: 22mm.
Motor Depth: 40mm.
Configuration: 2-phase bipolar, 4-wire.
