DC 3V 60RMP, N20 Metal Gear Motor
SKU: MOT-0041-Q01
Sold by Select Automation
Final price R 100.46
R 87.36 excl. VAT
Availability: In Stock (2 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Robust and efficient, the GA12-N20 Metal Gear 3V 60RPM Motor is ideal for a range of applications such as robots, automation systems, and do-it-yourself projects. This motor is well-known for its strong torque and accurate low-speed performance. Its all-metal gearbox guarantees robustness and long-lasting operation. Its steady 60 RPM speed while running at 3 V makes it perfect for jobs requiring slow, accurate action.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Model: GA12-N20
Rated Voltage: 3V DC
Revolving Speed (no load): 60RPM
Rated Current (no load): 0.02A
Revolving Speed (loaded): 50RPM
Rated Current (loaded): 0.04A
Rated Torque (loaded): 0.16 kg.cm
Stall Torque: 1.0 kg.cm
Stall Current: 0.20A
Reduction Ratio: 1:100
Total Length: 36mm
Gear Material: Full Metal
Gearbox Size: 9 x 12 x 10mm (L*W*H)
Shaft Size: ∅3 x 9mm (D*L)
Net Weight: 12g
Features:
Low RPM and high torque for precise applications
Robust gearbox made entirely of metal
Small and light in weight
Low noise operation
Ideal for a range of automation and robotics projects
