System module MS1020-0051-1145
SKU: MS1020-0051-1145
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The MS1020-0051-1145 module is a module for the direct supply of a 3-phase AC voltage and the DC link circuit for drive technology. Both voltages are connected in one cable by means of a 7-pin B23 connector. An additional module must be used for the EtherCAT connection.
Buy currently uses Select Automation shop pricing and checkout.
Product category: system modules
Category/version: power infeed
Output voltage power connector: 400 V AC/600 V DC
Output current power connector: 20 A
Connection method: B23
External supply voltage: 400 V…480 V AC/600 V DC
External feed current: 25 A max.
Baseplate interface: power connector
Diagnostics: yes
Hot swap: no
TwinCAT version: TwinCAT 3
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 30 mm × 110 mm × 72 mm
Number of rows: 1
Number of slots: 1
Material: zinc and aluminum die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
