system modules MS1432-1101-2349
SKU: MS1432-1101-2349
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The MS1432-1101-2349 module is a 3-phase power supply module with input fuses and black main switch for up to 32 A. A power supply unit with an output current of 18 A DC is already integrated to supply the 24 V DC system voltage. Furthermore, typical energy data such as current, voltage, active power, cos φ and frequency are recorded with this module.
Buy currently uses Select Automation shop pricing and checkout.
Product category: system modules
Category/version: power infeed
Output voltage data connector: 24 V DC
Output voltage power connector: 400…480 V AC
Output current data connector: 18 A
Output current power connector: 32 A
Connection method: terminal box
External supply voltage: 400 V…480 V AC
External feed current: 32 A max.
Energy measurement: yes
Color: black
Power supply unit: 24 V
Fuse: without
Baseplate interface: data and power connector
Diagnostics: undervoltage, overload
Hot swap: no
TwinCAT version: TwinCAT 3
Weight: 2600 g
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 110 mm x 240 mm x 174 mm
Number of rows: 2
Number of slots: 3
Material: zinc die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
