System module MS2204-0002-1112

product category: system modules Category/version: EtherCAT power infeed Output voltage data connector: 24 V DC Output voltage forwarding: 24 V DC Output current data connector: 4 A Output current forwarding: 4 A Connection method: M12 External supply voltage: 24 V DC External feed current: 4 A max. Distance between stations: max. 100 m (100BASE-TX) Baseplate interface: data connector Diagnostics: yes Hot swap: no TwinCAT version: TwinCAT 3 Weight: 400 g Approvals/markings: CE, (UL in preparation) Dimensions (W x H x D): 30 mm × 110 mm × 72 mm Number of rows: 1 Number of slots: 1 Material: zinc and aluminium die-cast Cooling: convection Operating/storage temperature: 0…+50 °C/-25…+85 °C Protect. rating/installation pos.: IP65/67/variable
