System module MS2306-0002-1111
SKU: MS2306-0002-1111
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The EtherCAT power supply module MS2306-0002-1111 is the link between the EtherCAT protocol and the MX-System modules. The integrated EtherCAT-P M8 connector is used not only to couple the data communication but also to feed the control voltage of 24 V DC with a total of up to 6 A (2x 3 A) into the MX-System.
Buy currently uses Select Automation shop pricing and checkout.
Product category: system modules
Category/version: EtherCAT power infeed
Output voltage data connector: 24 V DC
Output voltage forwarding: 24 V DC
Output current data connector: 6 A (2 x 3 A)
Output current forwarding: 6 A (2 x 3 A)
Connection method: M8
External supply voltage: 24 V DC
External feed current: 6 A max. (2 x 3 A)
Distance between stations: max. 100 m (100BASE-TX)
Baseplate interface: data connector
Diagnostics: yes
Hot swap: no
TwinCAT version: TwinCAT 3
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 30 mm × 110 mm × 72 mm
Number of rows: 1
Number of slots: 1
Material: zinc and aluminum die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
