System module MS2610-1002-1334

Product category: system modules Category/version: EtherCAT power infeed Output voltage data connector: 24 V DC Output voltage forwarding: 230 V AC Output current data connector: 7 A Output current forwarding: 7 A Connection method: B17 External supply voltage: 230 V AC External feed current: 10 A max. Distance between stations: max. 100 m (100BASE-TX) Power supply unit: 24 V Baseplate interface: data connector Diagnostics: yes Hot swap: no TwinCAT version: TwinCAT 3 Weight: 1100 g Approvals/markings: CE, (UL in preparation) Dimensions (W x H x D): 110 mm x 110 mm x 72 mm Number of rows: 1 Number of slots: 3 Material: zinc and aluminum die-cast Cooling: convection Operating/storage temperature: 0…+50 °C/-25…+85 °C Protect. rating/installation pos.: IP65/67/variable
