system modules MS4208-2003-1112
SKU: MS4208-2003-1112
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The module MS4208-2003-1112 is an EtherCAT power output for control voltages incl. EtherCAT communication. Power and data communication run combined via the EtherCAT-P single cable solution via M12 connector. Up to 8 A (2 x 4 A) on 24 V can be distributed to supply a remote control unit. The voltage can be switched off safely.
Buy currently uses Select Automation shop pricing and checkout.
Product category: system modules
Category/version: EtherCAT power output
Shutdown: yes
Output voltage forwarding: 24 V DC
Output current forwarding: 8 A (2 x 4 A)
Connection method: M12
Supply voltage from backplane: 24 V DC
Fuse: ntegrated
Baseplate interface: data connector
Diagnostics: yes
Hot swap: no
TwinCAT version: TwinCAT 3
Approvals/markings: CE, UL in preparation
Dimensions (W x H x D): 30 mm × 110 mm × 72 mm
Number of rows: 1
Number of slots: 1
Material: zinc and aluminum die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
