Digital Oscilloscopes, MSO3000X-ARINC429

Pricing available on request MSO3000X Series Digital Oscilloscopes: 4CH+16MSO. BW: 500/350 MHz Memory depth: 500 MB. Waveform capture rate is 800,000 wfms/s (sequence mode: 2,000,000 wfms/s). The 9-in-1 device includes a digital oscilloscope, logic analyser, function/arbitrary waveform generator, spectrum analyser, digital voltmeter, frequency counter, protocol analyser, Bode plot analyser, and power analyser. Parameter measurement statistics include histograms and trend charts. FFT enhanced by 4 million points. 54 waveform parameter measurements. Multi-window display. Zone trigger function. Ultra Phosphor 3.0 display technology. 10.1-inch 1280x800 HD capacitive touchscreen. Supports SCPI programmable instrument standard commands. Embedded Web Server.
