Digital Oscilloscopes, MSO3034X 350MHz 4Ch Mixed Signal Oscilloscope
SKU: MSO3034X
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
MSO3000X Series Digital Oscilloscopes:
4CH+16MSO.
BW: 500/350 MHz
Memory depth: 500 MB.
Waveform capture rate is 800,000 wfms/s (sequence mode: 2,000,000 wfms/s).
The 9-in-1 device includes a digital oscilloscope, logic analyser, function/arbitrary waveform generator, spectrum analyser, digital voltmeter, frequency counter, protocol analyser, Bode plot analyser, and power analyser.
Parameter measurement statistics include histograms and trend charts.
FFT enhanced by 4 million points.
54 waveform parameter measurements.
Multi-window display.
Zone trigger function.
Ultra Phosphor 3.0 display technology.
10.1-inch 1280x800 HD capacitive touchscreen.
Supports SCPI programmable instrument standard commands.
Embedded Web Server.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
MSO3000X Series Digital Oscilloscopes.
Scope Type MSO.
Bandwidth 350MHz
Channels 4Ch.
Scope Sample Rate 5.0GSa/s.
Memory Depth 500Mpts.
Refresh Rate 2,000,000wfms/s.
Vertical Scale @1MΩ 500μV/div to 10V/div.
Automatic Measurements 54.
Included Bus Protocols RS232 UART I2C SPI RS422 RS485.
Optional Bus Protocols CAN-FD Flex Ray SENT Audio MIL-STD-1553B ARNIC429 Manchester.
Logic Pod Included Optional.
Signal Generator Function Optional.
Frequency Meter 7-bit.
Display Size (in) 10.1in.
Touchscreen Yes.
Warranty 3 years.
Certifications CE/cETLus/UKCA.
