Digital Oscilloscopes, MSO5000HD-MANCH

Pricing available on request MSO5000HD Series, Digital Oscilloscopes: Analog channel bandwidth: 1 GHz, 500 MHz, 350 MHz The real-time sampling rate is 5 GSa/s. The vertical resolution is 12-bit. 4 analog channels and 16 digital channels. Memory capacity of up to 500 Mpts. The waveform capture rate is up to 800,000 wfms/s (in sequence mode, 2,000,000 wfms/s). 9 instrument features include a digital oscilloscope, logic analyser, function/arbitrary waveform generator, spectrum analyser, digital voltmeter, frequency meter, protocol analyser, bode plot analyser, and power analyser. Uninterrupted hardware real-time waveform recording and analysis of up to 400,000 frames. Up to 4 million points of enhanced FFT. 54 different parameter measurements, adds a line graph display and histogram. A display with multiple windows. 7-digit hardware frequency meter with several channels. DVM multi-channel RMS measurement includes DC, AC RMS, and DC+AC RMS. Protocol triggering and decoding functions include RS232/UART, I2C, SPI, I3C, 1-wire, CAN, CAN-FD, LIN, Flex Ray, Audio, MIL-STD-1553B, Manchester, SENT, and ARINC429. Zone trigger to capture irregular impulses and observe complex signals. A 10.1-inch 1280x800 HD capacitive multi-touch display. Webserver is integrated.
