Digital Oscilloscopes, MSO7000X-AWG

Pricing available on request MSO7000X Series, Digital Oscilloscopes: Analog channel bandwidth is 1G/2GHz. The maximum sample rate is 10 GSa/s. Maximum memory depth is 1 Gpt (standard setup). Waveform capture rates: 800,000 wfms/s (UltraAcq®) and 2,000,000 wfms/s (sequence mode). 11 different types of serial protocol analysis. A single machine with several functions: digital oscilloscope, logic analyser, spectrum analyser, function/arbitrary waveform generator, digital voltmeter, frequency counter, and protocol analyser. Up to 48 parameter measurements are supported, including histograms, tracking, and trend graphs. Advanced measurement and analysis functions include power analysis (optional), jitter analysis and eye diagrams (optional), mask and limit testing, histograms, and more. The operating system is Windows 10, 64-bit. 5.6-inch high-definition touchscreen. Embedded Webserver allows for convenient cross-platform access. Support the SCPI standard instrument programming commands. Enables MATLAB embedded programming and data presentation.
