Digital Oscilloscopes, MSO7000X-RM

Pricing available on request MSO7000X Series, Digital Oscilloscopes: Analog channel bandwidth is 1G/2GHz. The maximum sample rate is 10 GSa/s. Up to 1 Gpts of memory depth (standard configuration). Waveform capture rates: 800,000 wfms/s (UltraAcq®) and 2,000,000 wfms/s (sequence mode). There are eleven types of serial protocol analysis. A digital oscilloscope, logic analyser, spectrum analyser, function/arbitrary waveform generator, digital voltmeter, frequency counter, and protocol analyser are all included in one machine. Up to 48 different parameter measurement types are supported, including trend, tracking, and histogram graphs. Advanced measurement and analysis functions include power analysis (optional), jitter analysis and eye diagrams (optional), mask and limit testing, histograms, and more. The operating system is Windows 10, 64-bit. 5.6-inch touch screen with great definition. Cross-platform connectivity to an embedded web server is simple to accomplish. Support the SCPI standard instrument programming commands. Enables MATLAB embedded programming and data presentation.
