Bi-Metallic Thermostat, 250V 10A 180°C
SKU: OTH-0031-H01
Sold by Select Automation
Final price R 100.00
R 86.96 excl. VAT
Availability: In Stock (1 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
A bi-metallic thermostat is a temperature-controlled switch that uses a bonded bi-metal element to open or close an electrical circuit at a specific temperature.
A 180°C model is used to manage temperature or prevent against overheating in electrical heating equipment and appliances.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: Bi-Metallic Thermostat / Thermal Switch.
Rated Voltage: 250V AC.
Rated Current: 10A.
Operating Temperature: 180°C.
Switching Temperature Tolerance: ±3°C to ±5°C.
Contact Configuration: Normally Open (NO) or Normally Closed (NC).
Contact Resistance: ≤50mΩ initial value.
Insulation Resistance: ≥100MΩ at 500V DC.
Dielectric Strength: 1500V AC for 1 minute.
Service Life: ≥100,000 cycles.
Typical Terminal Type: 6.3mm quick-connect terminals.
Typical Application: Heating elements, ovens, coffee machines, electric appliances, heaters and over-temperature protection systems.
