AN7812 VOLTAGE REGULATOR 12 V 1A 3‑pin
SKU: REG-0011-B05
Sold by Select Automation
Final price R 14.29
R 12.43 excl. VAT
Availability: In Stock (7 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The AN7812 is a fixed, positive linear voltage regulator. It is perfect for use in power supply circuits because it is made to produce a steady 12 V DC output from an unregulated input supply.
With built-in protection features including thermal shutdown and short circuit protection, it can supply up to 1 A of output current and is packaged in a conventional 3-pin TO-220 form factor.
Due to its dependability and simplicity, it is frequently utilized in DIY power regulation projects, industrial equipment, and consumer electronics.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Type: Fixed positive linear voltage regulator.
Output voltage (nominal): 12 V.
Output voltage range: 11.4 V – 12.6 V.
Output current (max): 1 A.
Input voltage range: 14.5 V – 30 V (absolute max 35 V).
Dropout voltage (typical): 2 V.
Line regulation (max): 0.24%.
Load regulation (max): 0.24%.
Voltage tolerance (max): ±5%.
Package: TO‑220AB, 3‑pin.
Operating junction temperature: 0 °C to +125 °C.
Protection features: Thermal shutdown, short‑circuit protection.
