RM83, Miniature Relay, RM83-3021-25-1005

Specifications:   • Miniature relays • RM83-3021-25-1005, 1 NO ( SPST-NO), AgSnO2, 5V DC, Rated load AC1 16 A, Rated switching voltage 250 V AC, for PCB and sockets. IP40 • Mounting: For PCB and plug-in sockets • Cover protection category IP 40 or IP 67 EN 60529 • Number and type of contacts 1 CO, 1 NO, 1 NC • Contact material AgSnO2 • Rated / max. switching voltage AC 250 V / 400 V • Min. switching voltage 10 V • Rated load (capacity) AC1 16 A / 250 V AC, 20 A / 250 V AC (UL) • Rated load (capacity) AC15 6 A / 120 V, 3 A / 240 V (A300) • Rated load (capacity) DC1 16 A / 24 V DC • Rated load (capacity) DC13 0,22 A / 120 V, 0,1 A / 250 V (R300) • Motor load acc. to UL 508 1/2 HP 240 V AC, 4,9 FLA, single-phase motor • Motor load AC3 acc. to IEC 60947-4-1, 0,65 kW 240 V AC, single-phase motor • Min. switching current 10 mA • Max. make current 30 A 1 NO, AgSnO2 • Max. inrush current 120 A 20 ms • Rated current 16 A • Max. breaking capacity AC1 4 000 VA • Min. breaking capacity 1 W • Contact resistance ≤ 100 mΩ
