Commander S100-01S43-0A0000 AC drives
SKU: S100-01S43-0A0000
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Nidec Drives has a history of defying the existing quo and making significant contributions to the drive industry.
Nidec Drives is the first drive supplier to include NFC technology as standard and provide the Marshal app interface at no additional cost.
Marshal is your driving specialist in the field.
With this intuitive interface, you can easily commission, clone, diagnose system faults, and monitor drives.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Input Phases: 1 Φ.
Frame Size: 01.
Internal EMC Filter Performance: C3.
Heavy Duty:
Max Cont. Current (A): 3.5.
Motor Shaft Power (kW): 0.55.
Motor Shaft Power (hp): 0.75.
Overall Dimensions (±0.5 mm):
Height: 156 mm.
Width: 68 mm.
Depth: 130 mm.
Weight: 0.7 kg.
Mounting Dimensions (±0.5 mm):
DIN: 46 mm.
M1: 145 mm.
M2: 45 mm.
M3: 22.5 mm.
M4: 22.5 mm.
