50A 0-1200VDC SOLID STATE RELAY
SKU: SCI0501200
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
DC output solid state relay:
IGBT technology - for high DC voltage applications
SERIES: SCI series
SWITCHING CURRENT: 50A
SWITCHING VOLTAGE: 0 - 1200 VDC
PEAK VOLTAGE: 1200V
CONTROL VOLTAGE: 4.5 - 32 VDC
INDEX PROTECTION IP: IP20
DIMENSIONS (MM): (H) 58.5 x (W) 45 x (D) 27
Buy currently uses Select Automation shop pricing and checkout.
SCI series - Integrated reverse diode:
Control voltage range: 4.5-32VDC.
Max transient peak Voltage: 1200V
Advised max. DC Mains peak voltage: (Depends on protection clamping voltage)
Max. Load Current with heatsink: 50ADC.
DC Mains voltage range: (Depends on protection clamping voltage)
Load current range: 0 to 50A (with heatsink)
In & case / Out Insulation: 4kV
Connections: M3 and M5 round tabs
Control current: 35mADC.
Control current consumption: 25 – 42mADC.
Releasing control voltage: 1VDC
Max. reverse control voltage: 32VDC
Input impedance: Current limitation.
Display: Green LED (indicates the power element is controlled)
Housing: UL94V0
Mounting: 2 screws (M4x12mm)
Protection level: IP00
CE marking
UL, cULUS
