Board Mount Hall Effect/Magnetic Sensors, 20mA Bipolar, 3-Pin
SKU: SEN-0005-H11
Sold by Select Automation
Final price R 83.40
R 72.52 excl. VAT
Availability: In Stock (5 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The SS400 and SS500 Series are tiny and adaptable digital Hall-effect devices that operate on the magnetic field of a permanent magnet or an electromagnet.
They are designed to respond to alternating North and South poles, or to a South pole solely.
They are available in bipolar, latching, and unipolar magnetics.
On-board control ensures steady performance across the 3.8 Vdc to 30 Vdc supply voltage range.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Type: Bipolar.
Operating Supply Current: 10 mA.
Maximum Output Current: 20 mA.
Operating Point Min/Max: 60 G.
Release Point Min/Max (Brp): - 60 G.
Operating Supply Voltage: 12 V.
Minimum Operating Temperature: - 40 C.
Maximum Operating Temperature: + 150 C.
Mounting Style: Through Hole.
Package/Case: TO-92-Flat-3.
Supply Voltage - Max: 30 V.
Supply Voltage - Min: 3.8 V.
