95A 24-510VAC 1200V SS RELAY, IP20
SKU: SO768090
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Relays with solid states (SSR):
With an extremely long lifespan and back-to-back thyristors, all Celduc SSRs (solid state relays) use 4th generation TMS2 technology.
Buy currently uses Select Automation shop pricing and checkout.
General Features:
LED status control.
Input current that is regulated.
EMC appropriate for an industrial setting.
Protection against over-voltage on the input (transil) and output (RC and VDR).
Switching at random Solid-State Relay created specifically for motors and strong inductive loads (AC-53).
SO7 range for phase angle control applications and motor loads (AC-53) inductive loads.
As per IEC/EN 61000-4-4 (bursts) and IEC/EN 61000-4-5 (spikes), extremely high immunity.
Specifications:
SERIES: SO7
SWITCHING CURRENT: 95A
SWITCHING VOLTAGE: 24 - 510 VAC
PEAK VOLTAGE: 1200V
CONTROL VOLTAGE: 3.5 - 32 VDC
DESCRIPTION: Random for motor loads
INDEX PROTECTION IP: IP20
DIMENSIONS (MM): (H) 59.4 x (W) 45 x (D) 30
