50A 12-275VAC 600V SOLID STATE RELAY
SKU: SO845070
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
SSRs, or Solid-State relays:
Every Celduc SSR (solid state relay) has a very long lifespan and is equipped with back-to-back thyristors and 4th generation TMS2 technology.
Buy currently uses Select Automation shop pricing and checkout.
General Features:
Manage the LED status.
Controlled input current.
EMC suitable for use in an industrial setting.
SO8 range for infrared and light loads, respectively.
Protection against voltage on the input (transil) and output (VDR).
Zero-cross switching at a low threshold for zero-crossing (<12V).+
Extremely high immunity as defined by IEC/EN 61000-4-5 (spikes) and 61000-4-4 (bursts).
Specifications:
SERIES: SO8
SWITCHING CURRENT: 50A
SWITCHING VOLTAGE: 12 - 275 VAC
PEAK VOLTAGE: 600V
CONTROL VOLTAGE: 3 - 32 VDC
DESCRIPTION: Zero-cross for most loads
INDEX PROTECTION IP: IP20
DIMENSIONS (MM): (H) 59.4 x (W) 45 x (D) 30
