40A 12-280VAC 600V SOLID STATE RELAY
SKU: SO943460
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Solid state relays (SSR):
Every Celduc solid state relay (SSR) has a very long lifespan and is equipped with back-to-back thyristors and 4th generation TMS2 technology.
Buy currently uses Select Automation shop pricing and checkout.
General features:
Manage the LED status.
Controlled input current.
Protection against input overvoltage.
SO9 range (AC-51) for resistive loads.
Zero-cross switching made especially for loads that are resistive.
EMC appropriate for use in an industrial setting.
Very high immunity as defined by IEC/EN 61000-4-5 (spikes) and 61000-4-4 (bursts).
Specifications:
SERIES: SO9
SWITCHING CURRENT: 40A
SWITCHING VOLTAGE: 12 - 280 VAC
PEAK VOLTAGE: 600V
CONTROL VOLTAGE: 3 - 32 VDC
DESCRIPTION: Zero-cross for resistive loads
INDEX PROTECTION IP: IP20
DIMENSIONS (MM): (H) 59.4 x (W) 45 x (D) 30
