Short Description
The SONOFF MINI-DIM is an ultra-compact Matter over Wi-Fi smart dimmer switch that integrates intelligent dimming control into traditional lighting circuits while fitting neatly behind existing wall switches or inside normal mounting boxes.
As a Matter over Wi-Fi device, the MINI-DIM works perfectly with popular smart home ecosystems such as Apple Home, Google Home, Amazon Alexa, Samsung SmartThings, and Home Assistant, allowing for cross-platform control, automation, and voice commands.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Model: MINI-DIM.
Product Series: MINI Extreme Series.
Communication Protocol: Matter over Wi-Fi.
Wi-Fi Standard: IEEE 802.11 b/g/n.
Wi-Fi Frequency: 2.4GHz.
Supply Voltage: 220–240VAC.
Frequency: 50Hz.
Maximum Current: 2A.
Dimmable LED Load: Up to 200VA.
Incandescent Load: Up to 400W.
Halogen Load: Up to 400W.
Dimmable Electronic Transformer Load: Up to 200W.
Energy Monitoring: Yes.
Overheat Protection Yes
External Switch Support: Yes.
Housing Material: PC Flame Retardant.
Dimensions: 45 × 39.4 × 16.8 mm.
Operating Temperature: -10°C to +40°C.
Features:
Matter over Wi-Fi smart dimmer switch.
Ultra-compact design for installation behind wall switches.
Supports dimmable LED, incandescent, halogen, and transformer-based lighting.
Smooth flicker-free dimming with automatic or manual calibration.
Real-time power monitoring.
Built-in overheat protection.
Remote control via compatible Matter platforms.
Voice control support.
Scheduling, timers, and smart scenes.
Compatible with multiple external switch types.
Supports local LAN control through eWeLink.
No proprietary hub required for eWeLink operation.
