SONOFF Orb-ZBW2 Zigbee Double Smart Wall Switch | MINI-ZB2GS-E
SKU: SON-0186-F06
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The SONOFF Orb-ZBW2 Zigbee Double Smart Wall Switch (MINI-ZB2GS-E) is a two-channel smart wall switch that can operate two lighting circuits or electrical loads separately from a single wall switch.
It uses the Zigbee 3.0 protocol to provide fast, reliable, and low-latency communication while effortlessly integrating with SONOFF Zigbee hubs and compatible Zigbee ecosystems.
The switch offers Detach Relay Mode, which allows the physical wall switch and smart relay to work independently.
This ensures that smart bulbs remain powered for automation and remote control even when the wall switch is turned off.
The Orb-ZBW2 also serves as a Zigbee router (signal repeater), increasing the range and stability of your Zigbee mesh network.
It requires a neutral wire for installation.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product name: Orb-ZBW2.
Product series: Fusion series.
Model: MINI-ZB2GS-E.
MCU: EFR32MG21.
Rated specifications: 110-240V~ 50/60Hz 10A/gang, Total 16A MAX Resistive load.
Zigbee: IEEE 802.15.4.
Net weight: 96.5g.
Product dimension: 86x86x33.7mm.
Working temperature: -10℃~40℃.
Working humidity: 5%~95% RH, non-condensing.
Casing material: PC.
Certification: CE/RoHS.
