10 Way DIP Switch Slide Type
SKU: SWI-0008-H10
Sold by Select Automation
Final price R 14.73
R 12.81 excl. VAT
Availability: In Stock (68 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The 10-Way DIP Switch Slide Type is a small, PCB-mounted switch with 10 separate ON/OFF slide switches.
It is intended to configure configuration options, address, mode selection, and other programmable functions in electrical circuits and control systems.
Its compact size makes it ideal for applications requiring several manual switch settings in a limited location.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Type: DIP Switch.
Switch Type: Slide Type.
Number of Positions: 10.
Number of pins: 20.
Switch Function: ON/OFF.
Mounting Type: Through-Hole PCB Mount.
Number of Circuits: 10.
Actuator Type: Slide.
Application: PCB configuration, address setting, mode selection and electronic control.
Construction: Compact plastic housing with metal PCB terminals.
Operating Temperature: -20°C to +70°C.
