MULTI-RANGE, MULTI-FUNCTION TIMER 110VAC, FUNCTIONS: ON-DELAY, INTERVAL
SKU: T3M110A
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Multiple functions (four times as many) 4-time range multi-range:
Installing the Electro 11 pin plug-in series of control and timing devices is simple and straightforward since they are designed to fit into a conventional 11 pin base.
Multi-function timer based on a microprocessor, with four configurable modes of operation and a time range of 0.3 seconds to 60 hours.
Many applications because of the combinations of time intervals and functions.
A great degree of accuracy can be attained because of the unit's sophisticated design.
The unit has every function that is frequently utilized.
After the supply is provided, any adjustments made to the front potentiometer are not recognized.
This stops the time range from changing inadvertently.
Buy currently uses Select Automation shop pricing and checkout.
Features:
10A SPDT delay output repeatable deviation: less than 0.2%.
Design based on microprocessors.
Duration: 0.3 seconds to 60 hours.
10 A SPDT instantaneous output potentiometer with configurable time setting.
LEDs for power supply ON and relay ON.
Four function selectable rear DIP switches.
Eight timer ranges are selectable via the rear DIP switch.
Specifications:
TIME RANGE: 0.3 second - 60hours
DESCRIPTION: multi-function, multi-range electronic timer
CONTACT: 10A SPDT
FUNCTION: On-delay/ Interval/ Equal repeat/ Interval (pulse controlled)/ Instantaneous contact
RATED VOLTAGE: 250V
MECHANICAL LIFE: 10x106 cycles
PROTECTION INDEX IP: IP 20
OPERATING TEMPERATURE: -10 to + 50°C
STORAGE TEMPERATURE: -50 to + 85°C
DIMENSIONS (MM): (H) 92 x (W) 36 x (D) 64
