TwinCAT 3 I/O, platform level 60 (Mid Performance) TC1100-0v60
SKU: TC1100-0v60
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Using TwinCAT 3 I/O, cyclic data can be collected by different fieldbuses in process images. Cyclic tasks drive the corresponding fieldbuses. Various fieldbuses can be operated with different cycle times on one CPU. Applications can directly access the process image. The fieldbuses and the process images are configured in TwinCAT 3 Engineering.
Buy currently uses Select Automation shop pricing and checkout.
provides variable-oriented linkage of I/O devices to tasks
tasks are variable-oriented among each other
the smallest unit is one bit
supports both synchronous and asynchronous relationships
consistent exchange of data areas and process images
online display in the directory tree
online watch window
“Force and Write” for commissioning and for testing task variables and I/O devices
supported fieldbuses:
EtherCAT
Lightbus
PROFIBUS DP (master and slave)
Profinet (controller and device)
Interbus
CANopen
SERCOS II interface
DeviceNet
Ethernet/IP
Ethernet
USB
