TwinCAT 3 PLC/NC PTP 10/NC I/CNC, platform level 93 (Other 17…32 Cores) TC1270-0v93
SKU: TC1270-0v93
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Extension of the TwinCAT 3 PLC/NC PTP 10/NC I by the possibility to realize an interpolation with up to 32 simultaneously interpolating axes. The number of axes and/or the number of channels can be adapted to the requirements of the application via the option packages. Various transformations can be supplemented via option packages. Programming takes place according DIN 66025. The axes and channels are configured in TwinCAT 3 Engineering.
Buy currently uses Select Automation shop pricing and checkout.
19 path axes/controlled spindles, max. 64 axes/controlled spindles (optional), max. 12 channels (optional)
supports electric servo axes, stepper motor drives subroutine and jump technology, programmable loops, zero point shifts, tool corrections, M and H functions, mathematical functions, programming of parameters/variables, user macros, spindle and auxiliary functions, zero point shifts, tool functions
geometry functions: linear, circular and helical interpolation at the main levels and freely definable levels, max. 32 interpolating path axes per channel (optional), look-ahead function
axis functions, coupling and gantry axis function, override, axis error and sag compensation, measuring functions
programming in DIN 66025 with high-level language extension
access via function blocks from TwinCAT PLC according to IEC 61131-3
operation with automatic mode, manual mode (jog/inch), single block mode, referencing, block advance, handwheel mode (movement/overlay)
convenient debugging with online monitoring of all states
