TwinCAT 3 Filter Designer TE1310
SKU: TE1310
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The TwinCAT 3 Filter Designer is a graphic engineering tool for determining the coefficients of digital filters. In Microsoft Visual Studio® it integrates seamlessly with the existing TwinCAT 3 engineering environment.
Buy currently uses Select Automation shop pricing and checkout.
Selectable filter designs are Butterworth, Chebyshev and Inverse-Chebyshev, while the possible filter types are lowpass, highpass, bandpass and bandstop. The filter coefficients can be modified graphically or by means of a tabular specification. Once the filter coefficients have been determined, they can be used in the PLC as an input for digital filter function blocks or transferred into the ELM measurement modules by drag and drop. Each channel of an ELM measurement module has two freely configurable digital filters connected in series, which as a result are very easy to adjust using the Filter Designer.
