TwinCAT 3 Valve Diagram Editor TE1500
SKU: TE1500
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
In order to be able to move hydraulic axes in the same way as servo axes with TwinCAT NC PTP, the characteristic curve of a hydraulic valve, which is usually non-linear, must be linearized. The TwinCAT Valve Diagram Editor with graphical interface can be used for this purpose.
Buy currently uses Select Automation shop pricing and checkout.
On the basis of a few base points, straight lines or 5th degree polynomials can be determined that connect the points. Once the characteristic curve has been linearized, it can be loaded into the TwinCAT NC real-time and taken into account there. This allows hydraulic axes to be controlled in a similar way to servo axes.
