BF871 Transistor
SKU: TRA-0094-B11
Sold by Select Automation
Final price R 8.45
R 7.35 excl. VAT
Availability: In Stock (2 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The BF871 is a high-voltage NPN silicon transistor housed in a TO-202 plastic package, designed primarily for use in class-B video output stages of color television receivers. Manufactured by NXP Semiconductors (formerly Philips), it features low feedback capacitance, making it ideal for high-frequency applications where signal integrity is key. Its PNP complement is the BF872, allowing for complementary pair configurations in push-pull amplifier designs
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Type: NPN Silicon Transistor
Package: TO-202
Maximum Collector-Emitter Voltage (VCEO): 125 V
Maximum Collector-Base Voltage (VCBO): 125 V
Maximum Emitter-Base Voltage (VEBO): 5 V
Collector Current (IC): 1 A
Power Dissipation (PTOT): 1.5 W
Transition Frequency (fT): 100 MHz
DC Current Gain (hFE): 40 to 160
Application: Class-B video output stages, high-voltage switching
