TIP 145 Transistor
SKU: TRA-0095-B11
Sold by Select Automation
Final price R 10.51
R 9.14 excl. VAT
Availability: In Stock (1 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The TIP145 is a high-power PNP Darlington transistor designed for linear and low-frequency switching applications. It features a monolithic Darlington configuration with built-in base-emitter resistors, offering very high current gain and robust performance in demanding environments. Packaged in a TO-247 case, it’s ideal for use in power amplifiers, motor drivers, and voltage regulators. Its complementary NPN partner is the TIP142, making it perfect for push-pull designs.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Type: PNP Silicon Darlington Transistor
Package: TO-247 (Through-hole)
Collector-Emitter Voltage (VCEO): 60 V
Collector-Base Voltage (VCBO): 60 V
Emitter-Base Voltage (VEBO): 5 V
Collector Current (IC): 10 A
Peak Collector Current (ICM): 20 A
Power Dissipation (PTOT): 125 W
DC Current Gain (hFE): ≥ 1000 @ IC = 5 A, VCE = 4 V
Collector-Emitter Saturation Voltage (VCE(sat)): ~2 V
Operating Temperature Range: –65 °C to +150 °C
Complementary NPN: TIP142
