TwinCAT Valve Diagram Editor
SKU: TS1500
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Graphical tool for designing the characteristic curve of a hydraulic valve
Buy currently uses Select Automation shop pricing and checkout.
The TwinCAT Valve Diagram Editor allows the linearization of non-linear curves of hydraulic valves with the aid of a graphical editor. On the basis of a few base points, straight lines or 5th degree polynomials can be determined that connect the points. The characteristic linearization curve thus determined can be loaded into the TwinCAT NC real-time and taken into account when the voltages are output in the drive, enabling hydaulic axes to be controlled in a similar way to servo axes.
Operating system: Windows 7, Windows 10
Min. TwinCAT level: TwinCAT NC PTP
